After fitting and tuning a Unichip Q including a plug and play harness and an optional map select switch, this is now making a peak power of 94.1 kw
at the wheels!

Power Results:
From 80.8kw at the wheels.
To 94.1 kw at the wheels.

Torque Results:
From: 190nm at the wheels.
To: 230nm qat the wheels.

How does the Unichip work with your 3.4lt Petrol Prado:

Fuel Control: As 99.99% of factory cars come tuned VERY RICH, it makes sense to lean the fuel mixtures back to a safe area that enables the car to make good power without wasting fuel. With the Unichip we can blend the fuel trims only were required to correct the mass production "errors" allowing the engine to run more efficiently and ultimately last longer, the extra power produced is just a bonus!!

Ignition Timing Control: As with fuel control factory cars come with the ignition timing a long way away from ideal. With the Unichip we can optimise the ignition timing across the entire rev range, with Unichip "LIVE" timing and fuel adjustments are possible, this is the only true way of determining the best possible timing and fuel setting at each load site. Ultimately this will give the car more power, more torque and greater fuel economy. If the owner chooses to run premium unleaded fuel we can set the tune to take full advantage of the higher quality fuel.

Options:

Map Select : This option enables the 5 map capability of the Unichip Q. This means you can access the 5 maps which can be tailored to your requirements. EG, High octane Map, low octane map, Standard Map, Immobiliser Map or even a race fuel map. Speak to your Authorised Unichip agent to tailor 5 tunes to suit your application.
After fitting and tuning a Unichip Q including a plug and play harness and an optional map select switch, this is now making a peak power of 94.1 kw
at the wheels!

The New release suitable for Prado Plug & Play Unichip, ONLY available at Unichip Authorised Agents!
Australia's best Diesel Tuning Solution

Power Results:
From: 57rwkw
To: 73rwkw

Torque Results:
From: 224 nm
To: 342nm

How does the Unichip work on your Turbo Diesel suitable for Prado.

• Fuel Control: Unichip has complete 3D control over fuel volume across the entire operating range of the engine. This allows the Unichip Trained technician to increase or decrease the fuel volume as required to a safe level . This helps in keeping the Air Fuel Ratios within a safe limit.

• Injector timing: This is a unique Unichip feature to have complete 3D control of injector timing.This means we can control the exact time they open to achieve optimised burn of fuel. This will result in lower exhaust gas temperatures and greater engine longevity.

• Water temp Protection: This is a built in safety feature using a Unichip Q. We have the ability to monitor engine temp via the coolant temperature sensor. This allows the Authorised Unichip agent to manipulate the tune on a sliding scale as the engine temperature rises. Meaning: As the engine temperature rises the Unichip Q will intercept a signal, removing the fuel and timing slowly and in a controlled fashion to ensure it maintains maximum power and torque output, without compromising the engine.

Optional Extras

• Map Select: This option enables the 5 map capability of the Unichip Q+. This means you can access the 5 maps which can be tailored to your requirements. EG, High Power Map, Towing Map, Standard Map, Immobiliser Map or Even a High Boost or Low Boost Map. Speak to your Authorized Unichip agent to tailor 5 tunes to suit your application.

• EGT Protection: This is the "add on" safety feature of the Unichip Q+. We have the ability to monitor engine exhaust temp via the Unichip EGT sensor. This allows the Authorised Unichip agent to manipulate the tune on a sliding scale as the engine temperature rises. Meaning: As the engine temperature rises the Unichip Q+ will intercept a signal, removing the fuel and timing slowly and in a controlled fashion to ensure it maintains maximum power and torque output, without compromising the engine.

• Boost Control: This feature enables the Authorised Unichip agent to control boost pressure over the entire engine operating range with the Unichip Q+ and Boost Solenoid

Plug and Play pricing does not include fitting and tuning. Plug and Play Unichip will require fitting and tuning from Authorized Unichip agent.

SKU: PPTOY11.1-1

MODEL: Australias best Diesel Tuning Solution

Description:
Toyota158Q "Hard Wire" 2006 4lt

Power Increase:

From 106.4 rwkw
To 120.9 rwkw

The most impressive increase is at 3700rpm of 90rwkw increasing it to 109rwkw!
That's over a 21% increase of mid range power at the wheels!

Torque Increase:

From 90nm at the wheels at 3700 rpm.
To 109nm at 3700rpm.

How does the Unichip work with your 4lt Petrol Prado?

Fuel Control: As 99.99% of factory cars come tuned VERY RICH, it makes sense to lean the fuel mixtures back to a safe area that enables the car to make good power without wasting fuel. With the Unichip we can blend the fuel trims only were required to correct the mass production "errors" allowing the engine to run more efficiently and ultimately last longer, the extra power produced is just a bonus!!

Ignition Timing Control: As with fuel control factory cars come with the ignition timing a long way away from ideal. With the Unichip we can optimise the ignition timing across the entire rev range, with Unichip "LIVE" timing and fuel adjustments are possible, this is the only true way of determining the best possible timing and fuel setting at each load site. Ultimately this will give the car more power, more torque and greater fuel economy. If the owner chooses to run premium unleaded fuel we can set the tune to take full advantage of the higher quality fuel.

Optional Extras:

Map Select : This option enables the 5 map capability of the Unichip Q. This means you can access the 5 maps which can be tailored to your requirements. EG, High octane Map, low octane map, Standard Map, Immobiliser Map or even a race fuel map. Speak to your Authorised Unichip agent to tailor 5 tunes to suit your application.
After fitting and tuning a Unichip Q including an automated switch between fuels we are now making 120.9kw, an increase of 21%!
